• 2 Answers SOURCE: I had the same problem. There are two small light bulbs that illuminate the digital display, and they are burned out. You can easily replace them. The Aiwa part number for them is 8Z-KT1-641-010. The bulb is made by Sony, and the Sony part number is U0087654U. Nuptk Kabupaten Malang 2011 Obama there. I purchased them from Union Electronic Distributors: Note that the product is not an item they keep in stock, so it may take 1-2 weeks or more before you receive them. Here are the steps to replace the bulbs.

Sony CDC-X217 CD Player User Manual. STEREO CAR CD RECEIVER. RADIO-TOCADISCOS DE CD ESTEREOFONICO PARA. OWNER'S RECORD. For your convenience, record the model number and. Them when you contact your AIWA dealer in case of. Get Sony CDC-X217 - AIWA OPERATING INSTRUCTIONS STEREO CAR CD RECEIVER CDC-X217 YU. Get all Sony manuals! (Manual Memory)1 Press FNC repeatedly to select the desired band(FM1, FM2, FM3, AM1 or AM2).2 Press TUNEi or TUNEk to tune in to a desiredstation (see “Tuning in to a station,” page 3).

Aiwa CDC X217 - CD Receivers - 180 watts total power (45W x 4) Advanced H-Bass boost CD player CD-R compatible AM/FM stereo tuner.

Aiwa Cdc X227 Manual

You will need a small (#1) Phillips screwdriver and a soldering iron (low heat). A very small flat blade screwdriver (1/8') will also be helpful.

1) Remove the faceplate from the radio and bring it to a well-lit work table. 2) Remove the four Phillips screws on the back on the faceplate. 3) Carefully separate the back half of the faceplate cover from the front half. There are three locking tabs along the top, and three locking tabs along the bottom. Graco Pack N Play Newborn Napper Elite Setup. I used the small flat blade screwdriver to separate the two halves.

Aiwa Cdc-x217 Manual

4) Once the back half of the faceplate has been removed, re-install two of the Phillips screws to hold the circuit board in place (one screw on each end). You don't need to screw them down tightly; just screw them in until you begin to feel them stop. These screws will keep the circuit board from separating from the front faceplate and causing the buttons to fall out! 5) Locate the two bulbs. They are labeled PL 901 and PL 902 (may also be labeled PL 1 and PL 2). Carefully unsolder the bulbs and remove them from the circuit board. You may want to do one at a time.

6) Each bulb has a colored cover to change the color of the light (I jokingly refer to them as 'bulb condoms'). Remove the covers and carefully slide them in place on the new bulbs. You may want to slightly dampen the bulbs to aid in sliding the covers on. Be sure to slide them all the way down. 7) Solder the new bulbs in place. They are not polarity sensitive. 8) Trim off the excess wires.

9) If you installed the two screws in Step 4, remove them. 10) Carefully re-attach the rear faceplate cover to the front faceplate cover, making sure that all six locking tabs snap in place.

11) Put the four Phillips screws in the rear faceplate and carefully tighten them. Now, put the faceplate back on the radio, turn it on, and enjoy your lighted display!

Hope this helps. Ron Posted on Feb 15, 2009.
